FREQUENCY RESPONSE (+/- 4 dB) 33Hz – 20kHz
SENSITIVITY1 105dB @ 2.83V / 1m
POWER HANDLING (CONT/PEAK) 100W/400W
MAXIMUM SPL 121dB Continuous
NOMINAL IMPEDANCE 8 ohms Compatible
CROSSOVER FREQUENCY HF: 4500Hz
MF: 450Hz
HIGH FREQUENCY DRIVER K-771 1” (2.54cm) light-weight Polyimide
diaphragm compression driver mated to
a 90 x 40 Tractrix horn
MIDRANGE K-55-X 2” (5.08cm) Phenolic diaphragm
compression driver
LOW FREQUENCY DRIVER K-33-E 15” (38.1cm) Fiber-composite cone
woofer with a trihedral exponential
folded horn
ENCLOSURE MATERIAL Birch Plywood and MDF
INPUTS Dual binding posts / bi-wire / bi-amp
HEIGHT 53” (134.62 cm)
WIDTH 31.25” (79.38 cm)
DEPTH 28.25” (71.75 cm)
WEIGHT 220lbs (100 kg)
FINISH Satin Black Ash, American Walnut,
Natural Cherry
GRILLE CLOTH Silver Metallic
