SPECIFICATIONS
FREQUENCY RESPONSE (+/- 4 dB) 51Hz – 20kHz
SENSITIVITY1 105dB @ 2.83V / 1m
POWER HANDLING 100W / 400W
MAXIMUM SPL 121dB
NOMINAL IMPEDANCE 8 ohms compatible
CROSSOVER FREQUENCY HF: 4500Hz
MF: 450Hz
TWEETER
K-771 1" (2.54cm) Light-Weight Polyimide
Diaphragm Compression Driver Mated to
a 90° x 40° Tractrix Horn
HIGH FREQUENCY HORN Tractrix
MIDRANGE K-55-X 2” (5.08cm) Phenolic diaphragm
compression driver
MID-FREQUENCY HORN Exponential
WOOFER K-33-E 15” (38.1cm) Fiber-composite cone
with a folded horn
ENCLOSURE MATERIAL Birch plywood and MDF
ENCLOSURE TYPE Fully horn-loaded
HEIGHT INCHES (MM) 40” (101.6 cm)
WIDTH INCHES (MM) 24 1/4” (61.59 cm)
DEPTH INCHES (MM) 25 5/16” (64.29 cm)
PRODUCT WEIGHT LBS (KG) 201 lbs (91 kg)
FINISHES Natural Cherry, Satin Black Ash and
American Walnut
GRILLE CLOTH Silver Metallic
